| Description | Specification | Unit |
| Rated operating load | 5000 | kg |
| Bucket capacity | 2.5~4.5 | m³ |
| Machineweight | 17500±300 | kg |
| Dump clearance at maximum lift | 3100～3780 | mm |
| Reach at maximum lift | 1100～1220 | mm |
| Wheel base | 3300 | mm |
| Tread | 2250 | mm |
| Max.breakout force | 175±5 | KN |
| Max.horsepower | 160±5 | KN |
| Hydraulic cycle time-raise | ≤6 | s |
| Total hydraulic cycle time | ≤10.5 | s |
| Min.turning radius over tyres | 5925±50 | mm |
| Articulation angle | 38 | ° |
| Gradeability | 30 | ° |
| Tyre size | 23.5-25-16PR |
|
| Overall machine dimension L×W×H | 8225×3016×3515 | mm |
| Model | WD10G220E21 |
|
| Rated Power | 162 | KW |
| Travel speed | I-gear(F/R) | 13/17 | km/h |
| Ⅱ-gear(F) | 41 | km/h |
