| Description | Specification | Unit |
| Rated operating load | 3000 | kg |
| Bucket capacity | 1.5~2.5 | m³ |
| Machine weight | 10600±200 | kg |
| Dump clearance at maximum lift | 2770~3260 | mm |
| Reach at maximum lift | 1010~1210 | mm |
| Wheelbase | 2600 | mm |
| Tread | 1850 | mm |
| Height of hinge at maximum lift height | 3830 | mm |
| Working height(fully lifted) | 4870 | mm |
| Max.breakout force | 130 | kN |
| Max.horse power | 95 | kN |
| Hydraulic cycle time-raise | 5.5 | s |
| Total hydraulic cycle time | 10 | s |
| Min. turning radius over tyres | 5165 | mm |
| Articulation angle | 35±1 | ° |
| Gradeability | 28 | ° |
| Tyre size | 17.5-25-12PR |
|
| Overall machine dimension L×W×H | 7050×2482×3118 | mm |
| Model | WP6G125E22 |
|
| Emission standards | 国二 |
|
| Rated Power/Speed | 92/2200 | kW/rpm |
| Fuel Tank | 170 | L |
| Hydraulic Tank | 170 | L |
| Travel speed | Ⅰ-gear(F/R) | 8/10 | km/h |
| Ⅱ-gear(F/R) | 13/30 | km/h |
| Ⅲ-gear(F) | 24/- | km/h |
| Ⅳ-gear(F) | 40/- | km/h |
