| Description | Specification | Unit |
| Rated operating load | 6000 | kg |
|
| Bucket capacity | 3.0～4.5 | m³ |
|
| Machine weight | 20000±300 | kg |
| Dump clearance at maximum lift | 3170～3750 | mm |
| Reach at maximum lift | 1200～1360 | mm |
| Wheelbase | 3350 | mm |
| Tread | 2265 | mm |
| Max.breakout force | 205 | kN |
| Max.horse power | 174 | kN |
| Hydraulic cycle time-raise | ≤5.9 | s |
| Total hydraulic cycle time | ≤10.9 | s |
| Min. turning radius over tyres | 6005 | mm |
| Articulation angle | 38 | ° |
| Gradeability | 28 | ° |
| Tyre size | 23.5-25 |
|
| Overall machine dimension L×W×H | 8505×3220×3515 | mm |
| Model | SC11CB240.1G2B |
|
| Rated Power | 178 | kW |
| Travel speed | Ⅰ-gear(F/R)
| 6/6 | km/h |
| Ⅱ-gear(F/R) | 11/11 | km/h |
| Ⅲ-gear(F/R) | 22/22 | km/h |
| Ⅳ-gear(F/R) | 34/34 | km/h |
