| liem | Unit | XS203J |
| Service mass | kg | 20000 |
| Distributed mass of driving wheel | kg | 10000 |
| Distributedmass ofvibration wheel | kg | 10000 |
| Static line load | N/cm | 470 |
| Vibration frequency | Hz | 28/33 |
| Theoretical amplitude | mm | 1.9/0.95 |
| Exciting force | kN | 353/245 |
| Range of speed | ForwardⅠ | 2.95km/h |
| ForwardⅡ | 5.78km/h |
| ForwardⅢ | 9.4km/h |
| Wheel base | mm | 3230 |
| Compaction width | mm | 2130 |
| Theoretical gradeability | % | 30 |
| Minimum turn radius | mm | 6500 |
| Tire specification | 20.5-25-16PR |
|
| Diameter of vibration wheel | mm | 1600 |
| Minimum groundclearance | mm | 440 |
| Engine | Model | SC8D175.2G2B1 |
| Rated speed | 1800r/min |
| Rated power | 128kW |
| Overall dimension (length×width×height) 6220×2300×3200mm |
